Getting important, relevant information in front of your production team is essential in our world of shrinking deadlines and tighter schedules. The CADD Dashboard gives you the ability to put a web page or document in a dockable window right inside of Revit. The Dashboard also sends data from the active Revit model to that web page, which allows you to put fully customizable project or team specific information right in front of your Revit users.
- CADD Dashboard is a dockable web browser/file viewer right inside of Revit
- Push Revit project and user information through the Dashboard, for dynamic web pages to display customized project specific information
- It runs just like a webpage, making it immediately usable by Revit users
- Settings can be pushed and “locked down” from BIM or IT management, with an easy to use settings system





Dashboard for Revit

There's a lot more information in your Revit and AutoCAD files, and you don't need to open the programs to find it. The standard Windows file properties dialog box is pretty lacking, so FileProps lets you peek under the hood of your RVT and DWG files to get a little more crucial data.
- It works right in Windows - even on machines that don't have AutoACAD or Revit
- Just right-click on the file and select File Properties for AutoCAD/Revit





FileProps for AutoCAD and Revit

We love Revit and all it can do. But there is some basic functionality that we know would make every Revit user's life easier. FilterPLUS replaces the native Filter tool with a custom built, beefed-up filter that immediately makes your life easier.
- It allow users to not only filter by Category, but now by Family and Type as well
- FilterPLUS works in an expandable window that lets you resize it to see more information, as opposed to the "one size only" native Filter window
- The FilterPLUS interface is immediately understandable and easy to use by folks who have used the original Filter, but it has subtle tweaks that make it a better user experience
- No add-in to activate, just install FilterPLUS and it’s ready to go





FilterPlus for Revit

<div id="revit-toolbox">

### The Toolbox for Revit packages powerful tools together seamlessly directly inside the Revit interface. Insert Families from the Revit Content Pack, run Dynamo scripts, browse blogs, and more.

#### BIM MANAGER
<div class="toolbox-list">
<div><img src="https://amused-blushing-detail.media.strapiapp.com/element_guid_b038396bfc.png" /><div><strong>ELEMENT GUID:</strong> Revit has no effortless way to track down an element's GUID. This tool quickly and easily reports the GUIDs of the selected elements.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/export_project_parameters_f85f962134.png" /><div><strong>EXPORT PROJECT PARAMETERS LIST:</strong>Collects a list of all the active project's Project Parameters and exports to a CSV. Great for seeing what parameters you have, what you need, and align your projects data needs.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/export_images_55126e29be.png" /><div><strong>EXPORT IMAGES:</strong> Exports all images loaded into the active project into a specified folder.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/family_preview_aa07c526cf.png" /><div><strong>FAMILY PREVIEW IMAGE BATCH UPDATER:</strong> Select a folder of RFA files and this utility will create a new 3D view with consistent graphics across all the identified families. The view will be set as the preview image for a consistent group of thumbnails in Windows Explorer. Optionally, it can export the image.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/export_project_keynotes_8298290882.png" /><div><strong>EXPORT PROJECT KEYNOTES:</strong> Lose track of your keynote file? You can export it straight from your model to a text file that can be used for a new keynote file.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/set_units_to_imperial_13dc385473.png" /><div><strong>SET PROJECT UNITS TO IMPERIAL:</strong> This will overwrite all the project units to the default imperial setting. Useful if you started a project with the wrong template.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/set_units_to_metric_e4600ebaec.png" /><div><strong>SET PROJECT UNITS TO METRIC:</strong> This will overwrite all the project units to the default metric setting. Useful if you started a project with the wrong template.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/export_line_styles_974c5e63f3.png" /><div><strong>EXPORT LINE STYLES:</strong> Running this utility generates a CSV text file that lists the line styles and settings in the active document. Intended for quick review.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/batch_workset_7a0c581675.png" /><div><strong>BATCH WORKSET CREATOR:</strong> Create a batch of worksets at once from a simple list of workset names in a text file.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/backup_delete_43d45e5698.png" /><div><strong>BACKUP DELETE:</strong> Quickly delete all standalone project and family backup files - the .0001 and .0002 files, Run the utility, then select a folder and whether to delete in that folder by itself or to include all the subfolders as well.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/batch_file_update_b8bde8d464.png" /><div><strong>BATCH FILE UPDATE:</strong> Batch upgrade a folder or subfolder of RFA files to the current opened Revit version.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/family_export_cdf224e42a.png" /><div><strong>FAMILY EXPORT:</strong> This utility will attempt to save RFAs of the selected categories from the active Revit project. Select the target folder, categories you want to export, set your options, and Run the utility. Subfolders for each category will be created in the target folder.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/family_parameter_manager_d31bf4f5c9.png" /><div><strong>FAMILY PARAMETER MANAGER:</strong> Let’s you batch add, remove, and update parameters in selected RFA files.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/generate_family_file_locations_01fcf00faf.png" /><div><strong>GENERATE FAMILY FILE LOCATIONS:</strong> Generate an Excel document listing all the families in a specified folder. The Excel format allows Toolbox to load it via a mapping in the INI file.</div></div>
<div><img src="https://amused-blushing-detail.media.strapiapp.com/remove_view_ref_text_10b1aa59f8.png" /><div><strong>REMOVE VIEW REFERENCE TEXT:</strong> Removes View Type reference labels, like Sim, from all view types in the current document.</div></div>
</div>
</div>





Toolbox for Revit

The Warnings dialog in Revit can be a little tricky to navigate, which makes it more likely to users will overlook resolving important Warnings. WarningsPLUS for Revit adds a new interface with added functionality to make managing your Revit model warnings a little more manageable.
- We’ve made the Warnings window RESIZABLE!
- It replaces the current Warnings dialog box - no new button to click
- We’ve added the ability to sort and filter warnings to see exactly what you need to
- Warnings can be "ignored" to avoid low priority items
